MegaDumper™ Heavy-Duty Industrial Bin Lifter

MegaDumper employs the same efficient tipping geometry as the well-proven Dumpmaster machines. They are available with cradles to suit a range of larger bins, including 660l, 1000/1100l wheelie bins, or square and rectangular bins. Attachments are available to enable multiple bin sizes to be tipped, for example a cradle for tipping 1100l bins can be fitted with auxiliary catches to enable all standard wheelie bins from 80 litres up to 660 litres to be tipped as well. No adjustment is required for tipping the different sizes – simply wheel the bin in and empty it!

MegaDumpers can be made to tip at any practical height. They normally have a hot-dip galvanised frame and cradle, with zinc-plated guarding. However, some or all of the machine components can be made from stainless-steel for use in hygiene-critical areas or harsh environments.


Features of the Simpro MegaDumper


  • Power supply: 1-phase, 3-phase, battery, or compressed air
  • Full or partial stainless steel construction
  • Corrosion-resistant nickel-plated lifting chain
  • Frame-mounted tip chute
  • Bin hook kit to secure machine in position
  • Cradles to suit any type of bin or drum
  • Swing-up, left-hinge or right-hinge door
  • Category-3 Safety Certification
  • E-Stop button and master lockout switch
  • Dual side covers and controls
  • 'Door end' controls
  • Polycarbonate splash shield
  • Unbreakable PET-G guarding
  • 25mm fine mesh guarding
  • Steel front guard panel
  • Foot guard panels
  • Certified door latch
  • Auto-cycle controller
  • Solar panel
  • Digital scales


MegaDumper Specifications
Model (SKU) MD1200 MD1500 MD1800 MD2100 MDXXXX (Custom)
Tipping Height 1200mm 1500mm 1800mm 2100mm XXXXmm
Guarding Height 2635mm
Height 2855mm 3155mm 3455mm 3755mm XXXX + 1655mm
Length (door closed) 1442mm
Length (door open) 1692mm
Width 1874mm
Weight ~325kg ~350kg ~375kg ~400kg ~XXXX * 0.08 + 230kg
Max Bin Weight 600kg
Cradle Compatibility 660L, 1100L wheelie bins (options: custom cradle)
Bin Throw > 100mm
Electrical Specifications - Battery 2x 12v 21Ah sealed gel batteries in series configuration, driving 0.8kw DC motor drawing 60 Amps, with 24v DC control voltage
Electrical Specifications - Single-Phase 240v AC 50/60hz 1-phase mains supply, driving 0.75kw AC motor drawing 8 Amps via VSD (Variable Speed Drive controller), with 24v DC control voltage
Electrical Specifications - Three-Phase 400v AC 50/60hz 3-phase mains supply, driving 0.75kw AC motor drawing 1.9 Amps, with 24v DC control voltage
User Interface Raise/Lower buttons, key switch, battery indicator, master lockout switch (options: E-stop button, VSD control joystick)
Ingress Protection IP55 (options: IP56, IP69K)
Guarding 1.6mm sheet metal (options: transparent PET-G, 25x25x2.5 wire mesh, sheet stainless steel)
Corrosion Protection Hot-dip galvanised frame, galvanised cradle, zinc-plated guards (options: stainless steel)
Door Swing-up door with gas strut assist
Door Lock Solenoid-operated electrical safety interlock
Wheels ⌀200mm Blue Resilex castors (options: ⌀100mm castors, bolt-down lugs)
Applicable Standards and Certifications AS/NZS4024, ISO 13849-1, IEC 62061, Conformité Européene (CE), EN 349 1993, EN 574 1996+A1:200, EN 953 1997, EN ISO 4413 2010, EN ISO 12100 2010, EN ISO13849-1 2006, EN ISO 13857 2008, EN 60204 2006+A1 2009, EN61000-6-2 2005, EN61000-6-4 2007, Machinery Directive 2006/42/EC, Electromagnetic Compatibility Directive 2004/108/EC

Further Information is available on the manufacturer's website.
